Guardian GFR3500 Heated Safety Stations with Eyewash, Stainless Steel Construction, Top Inlet, Rated for Class I, Division 2 Environment

Application: These electric heat traced stations prevent freezing in even extreme conditions. Thermostat regulated units are heated by self-limiting heat-tracing cable wrapped around internal pipe. Units are intended for cold weather use down to -40 °F. See the Application Note in the right column concerning tepid water requirements under ANSI standards and applicable plumbing codes.

Heating Cable: Self-regulated with external termination guards. Thermostat activates when internal piping temperature falls below 75°F. FM, UL, and CSA approved for Class I, Division 2, Groups B, C, and D.

Electrical System: Unit is fully wired at factory. Junction box and components rated for Class I, Division 2, Groups B, C, and D. Requires 120 VAC single phase power supply.

Jacket/Insulation: UV-resistant orange ABS plastic with polyethylene foam insulation. Jacket sections secured with removable stainless steel screws for easy maintenance.

Shower Head: 10” diameter stainless steel with 20 GPM flow control.

Shower Valve: 1" IPS chrome-plated brass stay-open ball valve. US-made with brass ball and Teflon® seals. Includes stainless steel actuating arm and 29" stainless steel pull rod.

Spray Head Assembly: Freeze-resistant with float-off dust covers and internal flow control.

Eyewash Valve: 1/2" IPS chrome-plated brass three-way self-draining stay-open ball valve. US-made with brass ball and Teflon® seals. Includes 1/2" NPT port to drain water from spray heads after use.

Pipe And Fittings: Schedule 40 Type 304 stainless steel.

Supply: 1-1/4" NPT female top inlet. See item # GFR3510 for a version with a bottom inlet.

Sign: Furnished with ANSI-compliant identification sign, item # 250-008G.

Quality Assurance: Factory tested prior to shipment. Ships fully assembled and crated.

Alarm options: Alarm reflects the fourth digit of the model number as follows:

0 - No alarm.

1 - Single pole, double throw flow switch for remote sensing capability.

3 - Alarm horn and remote sensing capability.

5 - Light and remote sensing capability.

7 - Alarm horn, light and remote sensing capability.

Additional options which are priced on request include:

ALG Green area light.

FP Freeze protection valve.

HV 240 volt heat tracing.

PS Magnetically activated proximity (MAP) switch.

SP Scald protection valve.

SSH Stainless steel shower head.

TL Heat trace indicator light.
